The Hardening Linux by James Turnbull. The patch that most interested me was to prevent executable code from running in the stack. That won't prevent all CONFIG_HARDEN_STACK=y
# CONFIG_HARDEN_STACK_SMART is not set
CONFIG_HARDEN_LINK=y
CONFIG_HARDEN_FIFO=y
CONFIG_HARDEN_PROC=y
CONFIG_HARDEN_RLIMIT_NPROC=y
I then ran the typical "make dep" etc. and after a long, long wait everything completed and I ran "make install". That broke, complaining
grubby fatal error: unable to find a suitable template
Grubby? I had never heard of it, but "man" showed me that it is used to update /etc/lilo.conf or /etc/grub.conf. The man page mentioned templates, but didn't explain enough to tell me what its problem might be. However, looking in /boot, I could see that everything I needed had been installed there, so I went ahead and edited /etc/grub.conf by hand. Unfortunately, I fat fingered it and ended up with this:
# NOTICE: You have a /boot partition. This means that
#
all kernel and initrd paths are relative to /boot/, eg.
#
root (hd0,0)
#
kernel /vmlinuz-version ro root=/dev/hda2
#
initrd /initrd-version.img
#boot=/dev/hda
default=0
timeout=10
splashimage=(hd0,0)/grub/splash.xpm.gz
title Red Hat Enterprise Linux ES (2.4.29-ow1)
root (hd0,0)/grub
kernel (hd0,0)/vmlinuz-2.4.21-27.0.2.EL ro root=/dev/hda2 hdb=ide-scsi
initrd (hd0,0)/initrd-2.4.29-ow1.img
title Red Hat Enterprise Linux ES (2.4.21-4.EL)
root (hd0,0)/grub
kernel (hd0,0)/vmlinuz-2.4.29-ow1 ro root=/dev/hda2 hdb=ide-scsi
initrd (hd0,0)/initrd-2.4.21-27.0.2.EL.img
Do you see the mistake? It should have looked like this:
# NOTICE: You have a /boot partition. This means that
#
all kernel and initrd paths are relative to /boot/, eg.
#
root (hd0,0)
#
kernel /vmlinuz-version ro root=/dev/hda2
#
initrd /initrd-version.img
#boot=/dev/hda
default=0
timeout=10
splashimage=(hd0,0)/grub/splash.xpm.gz
title Red Hat Enterprise Linux ES (2.4.29-ow1)
root (hd0,0)/grub
kernel (hd0,0)/vmlinuz-2.4.29-ow1 ro root=/dev/hda2 hdb=ide-scsi
initrd (hd0,0)/initrd-2.4.29-ow1.img
title Red Hat Enterprise Linux ES (2.4.21-4.EL)
root (hd0,0)/grub
kernel (hd0,0)/vmlinuz-2.4.21-4.EL ro root=/dev/hda2 hdb=ide-scsi
initrd (hd0,0)/initrd-2.4.21-27.0.2.EL.img
That gave me a lovely "file not found" when I attempted to boot. Not quite realizing what I had done, I then tried to boot the second kernel, and of course that failed with the same error. Looking more closely, I spotted my problem and used the "edit" capability of grub to point it at the right kernel.
That got me back up again. Openwall includes the source code for a program to test the stack changes, so I compiled that and tried it out:
cd /usr/src/linux-2.4.29-ow1/optional
gcc -o stacktest stacktest.c
Attempting to simulate a buffer overflow exploit...
Segmentation fault
I still haven't found out what template is needed for grubby, but I did find a patch for it: APLawrence.com
A.P. Lawrence provides SCO Unix and Linux consulting services http://www.pcunix.com
