Apple's Mac OS X makes broad use of Adobe's PDF technology. It is the first example to date of an operating system that contains an actual Adobe Normalizer embedded as a system component. A careful analysis shows that Apple hasn't yet delivered on the exciting promise of an operating system built around PDF. For the world's publishers, Mac OS X is a blessing -- no question about that. Publishers have never had an operating system that is this fast and this publishing-oriented. OS 9 users may not want to hear it (in some cases, they may have to be dragged kicking and screaming to OS X), but they, too, will soon learn to appreciate the advantages of OS X. A few months ago, Apple publicly introduced the latest operating system release, version 10.3, code-named "Panther." It no longer relies on Display PostScript for its display format (as did the NeXT operating system -- here one clearly sees the influence of Steve Jobs) but rather on PDF technology. PDF is one of the internal graphics formats; it is used in the "Quartz" module of the OS, which is responsible for 2D graphics. This has the important result that it is no longer necessary to have any additional software to create and display PDFs. But don't jump to any conclusions; as we'll discuss below, this capability is largely irrelevant for printing and publishing applications. Another major innovation of OS X compared with other operating systems is how closely it dovetails with the integrated ColorSync color-management technology. ColorSync provides support for accurate color display and for working with ICC profiles. Great for Viewing, Not Output Even though the Apple PDF applications depart from the familiar working methods of Adobe's family of programs, many users from the publishing industry will likely depend more heavily on the Apple-supplied technology than on Acrobat Reader. The OS X viewer, called Preview, opens even enormous PDF files very rapidly. Preview facility is much superior to Acrobat when all you want is simple viewing and navigation through PDF files. For example, Preview requires only 2-3 seconds to launch, and it can open a 200-page PDF document in just 2 more seconds. Immediately after that, the full-text search facility is available. It works without indexing, but it is nearly as fast as the index-based Acrobat search. A list of hits (with links to the corresponding points in the document) appears within 10 seconds after entry of the search string. Integrated tools for the selection of text and graphics permit the program to be used as an "intelligent" intermediate format for the rapid transfer of information between files. And none of this requires generating an index in advance. After a normal Acrobat installation in OS X, Acrobat always launches as the viewer for PDF files. If you want Preview to be the default instead, you have to let the system know via the Get Info dialog box. Note that it is now necessary (in contrast to OS 9) to have the file name end with ".pdf." Not every element of a PDF file is correctly displayed in Preview. Transparencies, though, are shown correctly.
Sidebar and NotesThe Hidden PDF Features
Some of Panther's PDF services are initially hidden from the user. In order to make what appears on your screen look like the screenshots in this article, it is necessary to activate the hidden services. Here's the trick: First, create an empty folder called "PDF-Services" in the Library directory. Once the PDF Service function is activated in this way, various services defined by the user (so-called "droplets") can be placed in the folder. They then become directly available via the print dialog. A droplet can simply be a folder in which the new PDF is to be placed (the simplest case), or the alias of a program (e.g., a mail program) to which the operating system is to direct the PDF file once it is created. Similarly, AppleScript programmers can intercept these PDF files using AppleScripts.
Notes
1. In the 10.2 "Jaguar" release, Apple offered only Quartz, which was written entirely within Apple, for PDF generation. Realizing that this wasn't up to graphic arts standards, Apple licensed Adobe code for Panther.
2. These folder names may be different in different languages. A user of the German operating-system version would see Programme instead of Applications, and /Users/Shared/Adobe PDF 6.0 would be /Benutzer/Fr alle Benutzer/Adobe PDF 6.0. While Apple deserves to be complimented for this powerful little Preview tool, its choice of which PDF specification to support is less praiseworthy. While OS X 10.3 does support PDF up through version 1.4, including transparency, many features of PDF are not directly supported. This means that these functions are not displayed, and they do not appear in the printed PDF either. Missing features include annotation, video, and sound, as well as many functions that are urgently needed by publishers. One looks in vain for support for transfer curves and OPI comments, for example. The settings for the overprinting function are missing, as is support for Illustrator's overprint mode. Trimbox, artbox, and bleedbox settings are missing, as are references to external files, Xobjects, alternate images, and XML tags. Even the use of JavaScript and form fill-in is missing.
, creating a PDF file from an application is simply a matter of selecting )
- The situation is similar with color definition. Since the same routines are used both for PDF file creation and for screen rendering, colors in the PDF are specified as RGB only. This method is very similar to the discredited method used by PDF Writer for PDF creation. PDF Writer is a tool that every publisher must prevent its customers -- and above all, its employees -- from using. For example, if you use PDF Writer, you can expect to lose all font information. If you still choose to use the Apple-provided functions built into the operating system, it is possible to produce a PDF that may be usable for printed output, but only if you can live with limitations such as those listed above. This is especially true when creating PDFs out of Microsoft Office. Normalizer and ColorSync: better things to come? For PDF creation from professional layout applications or EPS files used in office programs, it is still necessary to take a PostScript-based approach, given that direct PDF creation is often insufficient. Apple's developers recognized this and tried to provide a workaround. Apple integrated a reduced-functionality version of the Adobe Normalizer (see Note 1 at left) into OS X 10.3 so that PDFs could be generated from PostScript documents. Here, too, Apple stuck to the principle of "keep it small and simple." Alas! PDF creation is simple, true enough. All you need is an EPS or PostScript file and the Preview program. PDF generation is initiated by dragging the PostScript file onto the icon of the Preview program. PDF conversion starts immediately, which is indicated by a pop-up conversion window. A short time later (roughly the same time that Distiller would take), the file is ready. But the result is not very exciting, as you will see shortly. The Normalizer module (the OEM version of Adobe's Acrobat Distiller) is sold by various integrators and can be found in systems from Agfa, Creo, Heidelberg, and many others. But, in most cases, it is provided with a system-specific user interface and with significantly enhanced functionality. Generally, there are parameter settings that are specifically designed to work with the OEM product. Probably the most prominent examples are Prinergy, Metadimension, and Apogee, all of which have long used the Adobe Normalizer. In Mac OS X, however, there are no user-controlled parameters available. They have all been predefined by Adobe and cannot be modified. So, for example, it is not possible to specify that images are to be downsampled or compressed. Colors cannot be changed, and transfer curves are simply deleted. So are overprint settings. When fonts are used, subsets are created starting from 1 percent; and if a font is missing, a warning is issued -- but the PDF is still created. DSC comments, including OPI comments (important in many workflows), are likewise missing. Stepped gradients are not recognized and are therefore not replaced with smooth gradients, and Illustrator's overprint mode is not supported. So this is definitely a bare-bones version of the Adobe Normalizer. Apple has not explained why it didn't take this a step farther. The only thing we can think of is that Apple didn't want to spoil its business relationships with other Adobe OEMs. Publishers will just have to deal with the problem that PDFs created in this way can frequently reach formidable sizes, due to the lack of downsampling and compression. Fonts that are embedded as subsets can lead to repeated problems later in the workflow, especially when a piece of text urgently needs to be corrected shortly before the PDF goes to press or when several PDF files from earlier versions of a program have to be combined. ColorSync and PDF creation. The Quartz ColorSync Filter provides tools with which PDF documents can be modified. If you think only in terms of color when you think about ColorSync, you will be shortchanging yourself. Behind the menus (which are somewhat awkwardly linked together) are hidden a number of practical functions. These can be logically separated into five areas: color-space conversion, image optimization, resolution adjustment, image compression, and PDF/X creation. But the settings for these options are remarkably well hidden from the normal user. The whole user interface is hidden away in the ColorSync service program. Unfortunately, Apple seems to think that there is no compression except ZIP (also called LZW or Flate) compression. This is the only type of compression available for direct PDF creation. The ZIP algorithm gives significant compression only with "artificial" images (e.g., screen shots). But at least it has the advantage of being lossless. It is also sad that every PDF created directly by the Quartz module in OS X 10.3 exhibits the "Generic RGB Profile," regardless of what ICC profile was set as the system standard. This means that, while it is possible to create PDF/X-3 files, no other color profile can be used. This is not exactly what the inventors of PDF/X-3 had in mind! In the current version of OS X (version 10.3.2), this must really be viewed as a "technology preview"; it suffers from problems of stability as well as lack of user-friendliness. What with one problem or another, we can only advise publishers not to use this tool.
.</i>
<b>Creating PDF/X files in practice</b>. Even though most of the items on a publisher's wish list are only partially addressed by OS X, it is still interesting to explore how PDF/X files can be created via ColorSync. Apple will surely fix the problems listed above fairly quickly, and the principles (once you find the required menus) are really very simple.
The simplest way to create a PDF/X is by selecting it directly from the print dialog in the application (for example, MS Word). In this case, OS X creates a PDF file and deposits it on the desktop. If the user launches the ColorSync service program and then opens the PDF file via the Open dialog in the File menu, it is immediately displayed. The user is given access to a predefined set of functions, and it's also possible to create a personal set. But to make the PDF file into a PDF/X file, a series of steps is required.
<img src=)
Figure 3: In the Panther version of OS X, Apple has greatly improved its PDF generation tools and now supports PDF/X-3 output. Because this is a function of the operating system, it is available to any application that can print, even if the application itself knows nothing about PDF.
First, the Images item in the middle drop-down menu must be selected. This gives the user choices such as sampling, compression and convolution. The "automatic compression" choice here would be ideal, if it were not for a program bug that allows only the lowest level of JPEG compression to be chosen. Another click back on the top menu takes the user to the "PDF" selection. There, under "Image interpolation," it is possible to activate bicubic downsampling. The next step is to select "PDF/X-3:2002" in the lower drop-down menu. There, "General Information" can be added -- in the case of PDF-X, this can be specifications about trapping and about the trimbox and bleedbox. This is also where output conditions can be specified. (It is worth noting that the ability to specify the appropriate color profile would fit here nicely.) Under the "Target" item, it would be possible to specify the target profile, if Apple hadn't left another bug in the code. At a minimum, it is important to at least note where the recipient can download the appropriate profile. (The PDF/X-3 specification permits this approach.)
Alternative Power Source for OS X
Users who want a better way of dealing with OS X should take a close look at PDF Enhancer from the U.S.-based vendor Apago (
Figure 5: Apago's PDF Enhancer lets you define any number of targets (ours are listed in the left pane of the window) and, for each target, select the parameters that will optimize the file for its intended purpose.
The application of the software is very straightforward. The Enhancers (components) of PDF Enhancer each have at least one (in some cases, optionally more than one) processing step associated with them. A processing step (called a target) works with individual components of a document (or the document as a whole), based on settings that are arranged in different groups. This includes such things as downsampling and compression of images, conversion of RGB and spot colors, and a limited imposition function. It turns out to be useful to keep each processing step as simple as possible, and then combine several processing steps into a complex workflow. That way, you always have an overview of all the processes.
Once such a set of processes has been defined, the user has a number of options. The file to be processed can be opened in the application, a watched folder can be set up, or a "folder action" can be applied. Folder actions are a new feature of Panther. The action can be attached to a folder via the Apple Finder, and it will be launched every time the content of the folder changes. When multiple folders have to be monitored, this approach has the advantage over watched folders that the operating system doesn't have to constantly check all the folders, resulting in better performance. Another benefit is that the application doesn't need to run constantly in the background, since the system will launch it whenever the contents of the folder change.
But Apple has also provided broad workflow capabilities right in the Panther operating system, including "PDF Services." If the workflow described above is defined as a PDF Service, it will be directly available from the print dialog. When doing this, it is still important to specify in PDF Enhancer a folder for the file that is produced. Otherwise, it will be placed in a temporary folder that the user cannot access directly.
. More precisely, these are the installed program )
Conclusion
Mac OS X 10.3 isn't always easy on the user, but it offers such an enormous performance boost that switching is unavoidable. It is still advisable, though, to handle PDF generation for prepress and print production in the "traditional" way. That will remain the case until Apple and Adobe make the Normalizer and the associated operating system functions a bit more suitable for use by print professionals.
What Apple has done makes sense as an effort to reinforce its position within the printing and publishing industry, but it also indicates that Apple is out of touch with the industry's actual needs. In terms of useful functionality (or even user-friendliness) for the average user, Apple missed the mark with this initial effort. Nevertheless, it represents a first step, and we are eager to see what Apple does next in response to the many criticisms it has been getting.
CreativePro.com
Bernd Zipper is a business and technology consultant specializing in PDF, new media and cross-media publishing projects. His also the publisher of the German news site pdfnews.de. He can be reached at peter@inpetto.de.
