The dse084 DSP Engine (DSP Engine 084) is a 28‑nm, custom, SIMD‑based accelerator designed to deliver high‑throughput, low‑power digital signal processing for embedded, industrial, telecommunications, and safety‑critical applications. This document provides a detailed technical briefing, covering architecture, key features, performance data, security considerations, and real‑world use cases.
System Architecture
Core Design
The dse084 is a 128‑bit SIMD datapath, configurable via a ring‑based interconnect. It supports parallel addition, subtraction, multiplication, and MAC operations. Each core contains two memory banks (8 KB local SRAM) and a 32‑register file.
Instruction Set
Fixed‑point and floating‑point operations are encoded in 32‑bit instructions. The core is designed for zero‑overhead branching, supporting nested loops and SIMD operations in a single cycle.
Programming Model
Code is written in C and compiled with the dse084 SDK. The compiler maps loops to SIMD lanes, handles data‑flow dependencies, and emits a compact 32‑bit instruction stream.
Key Features
- High Throughput: Supports 8 parallel lanes, achieving up to 1.2 TOPS in the current 28‑nm implementation.
- Low Power: Idle leakage
- Programmability: Supports custom kernels, user firmware, and embedded software via the dse084 SDK.
- Security: Built‑in tamper detection and secure boot with AES‑256 key storage.
Performance Metrics
| Metric | Value |
|---|---|
| Peak Compute Rate | 1.2 TOPS |
| Peak Memory Bandwidth | 6.4 GB/s |
| Power Consumption (Active) | 120 mA @ 2 GHz |
| Power Consumption (Idle) | 18 µA |
| Die Area | 12.4 mm² |
| Operating Voltage | 1.35 V |
Security & Reliability
Secure Boot & Key Management
Bootloader verifies firmware integrity using a 256‑bit SHA‑256 hash. AES‑256 encryption keys are stored in a tamper‑detected, 128‑bit key store. Tamper events trigger a secure reset and key erasure.
Fault Detection
Built‑in error‑correcting codes (SECDED) on the SRAM banks detect and correct single‑bit errors. The compiler injects dummy instructions to reduce side‑channel leakage, achieving a 30 % reduction in power‑analysis risk.
Use Cases & Benchmarks
- Real‑Time Audio Processing – Implemented in the AudioShield 3.0 board; achieved 50 dB SNR at
- Industrial Vision – Used in VisionCore V5 for edge AI; 25% faster inference compared to generic ARM cores.
- Telecommunications – Accelerated 5G baseband; achieved 3 × lower latency and 30 % lower power vs. conventional ASIC.
- Medical Imaging – Embedded in MRI coils; compliant with IEC 60601‑2‑61, delivering real‑time reconstruction.
- Automotive DSP – Integrated in EuroAuto's ADAS stack; provided 10 ms sensor‑fusion latency at
Performance Validation
- 32‑bit FIR filter (512 taps): 100 % throughput at 120 µs latency,
- 8‑bit SIMD convolution: 2.4 TOPS at 2 GHz, 1.8 W.
- 128‑bit FFT (2⁷‑point): 20 ms latency,
- VLSI test‑chip yielded 98 % functional yield across 400 devices.
Future Roadmap
- 16‑nm iteration expected 2025 with 30 % power savings.
- Extended SDK libraries for TensorFlow Lite and ONNX.
- Edge‑AI integration with secure OTA updates.
Conclusion
The dse084 DSP Engine offers a compelling mix of performance, power efficiency, and security, making it suitable for a broad spectrum of embedded and safety‑critical domains. Its custom SIMD architecture and robust software ecosystem provide a flexible platform for rapid deployment and future scalability.
