Introduction
The term garbage start refers to the event marking the beginning of a garbage collection cycle in managed runtime environments such as the Java Virtual Machine (JVM). When a JVM initiates a collection, it records a GarbageCollectionStart event, which signals the transition from normal application execution to memory reclamation. This event is central to performance monitoring, profiling, and tuning because it captures the point at which the runtime shifts resources from allocation to reclamation. The event is part of a larger suite of instrumentation features that allow developers and system administrators to observe the internal behavior of virtual machines without intrusive debugging or significant overhead.
History and Background
Managed runtime environments emerged in the early 1990s to provide automatic memory management and platform independence. The Java language, released by Sun Microsystems in 1995, introduced a garbage collector as a core feature. Initially, garbage collection was a simple stop‑the‑world algorithm, and developers relied on coarse metrics such as heap usage to infer collection behavior. Over time, the need for detailed diagnostics led to the introduction of tracing mechanisms. In Java 7, Oracle added jstat and jcmd commands to probe GC internals, but these tools were limited in granularity and portability.
The introduction of Java Flight Recorder (JFR) in JDK 8 marked a significant advance. JFR provided a low‑overhead, high‑resolution event recording framework that could capture a wide range of runtime activities, including garbage collection start and end events. JFR's event model allowed developers to configure which events to record, at what granularity, and for how long. Subsequent JVM implementations, such as OpenJDK HotSpot, OpenJ9, and Android Runtime (ART), integrated JFR and extended its event set, making the GarbageCollectionStart event a standardized part of JVM instrumentation.
Definition and Key Concepts
Garbage Collection Start Event
The GarbageCollectionStart event is a timestamped marker generated by the JVM when it enters a garbage collection phase. The event typically contains the following fields: the unique identifier of the GC algorithm (e.g., G1, CMS, Parallel), the size of the heap before collection, the number of objects eligible for collection, and the start time in high‑resolution nanoseconds. In JFR, the event is defined as a java.lang.management.GarbageCollectionStart with the EventType set to START and the corresponding stop event generated at the end of the collection.
Event Lifecycle
A typical garbage collection cycle involves the following stages: allocation of objects, marking of live objects, and sweeping or compacting of unreachable objects. The GarbageCollectionStart event is emitted immediately before the marking phase begins. After the cycle completes, a GarbageCollectionFinish event is emitted, providing metrics such as the duration of the collection, the amount of memory reclaimed, and the number of objects processed. By pairing start and finish events, analysts can compute the exact duration of individual GC pauses and correlate them with application performance metrics.
Implementation in Java Virtual Machines
HotSpot
HotSpot’s implementation of GC start events is tightly coupled with its JFR integration. HotSpot supports several collectors, each with its own start event semantics:
- Parallel Scavenge – Uses a stop‑the‑world, multi‑threaded minor GC. The start event includes the size of the young generation and the number of threads involved.
- CMS (Concurrent Mark Sweep) – Begins with a stop‑the‑world pause for initial marking. The start event indicates the mode (Initial Mark, Concurrent Mark, Final Remark) and the current GC cycle number.
- G1 (Garbage First) – Divides the heap into regions. The start event captures the number of regions being processed and whether the collection is concurrent or stop‑the‑world.
HotSpot emits a GarbageCollectionStart event for each pause, even for concurrent phases where the application continues running, to provide visibility into the full GC lifecycle.
OpenJ9
IBM’s OpenJ9 JVM also implements GC start events in its JFR data model. OpenJ9 offers a range of collectors, including a generational collector, a concurrent collector, and a parallel collector. OpenJ9’s GarbageCollectionStart event includes fields such as gcType, heapBefore, and heapAfter. The event is emitted at the beginning of any pause or concurrent GC activity, allowing users to distinguish between full and incremental collections.
Android Runtime (ART)
The Android Runtime (ART) uses a compacting, generational GC optimized for mobile devices. ART records GC start events in its logcat output and can expose them through the adb shell dumpsys command. The event includes the allocation pool (e.g., heap, Eden), the size of the pool before collection, and the reason for the collection (e.g., low memory, GC trigger). While ART does not use JFR, its logging infrastructure serves a similar purpose, providing developers with insights into GC behavior on Android devices.
Impact on Performance and Profiling
Measurement and Analysis
Accurate measurement of GC pauses is essential for performance optimization. Tools such as jcmd GC.class_histogram, jstat -gc, and JFR provide granular data:
- JFR – Records start and finish events with nanosecond precision. Analysts can extract traces and filter by event type to isolate GC-related data.
- VisualVM – Integrates with JFR and offers real‑time monitoring of GC activity, visualizing pause times and heap utilization.
- Prometheus + Grafana – By exposing JFR metrics via exporters, teams can build dashboards that correlate GC pauses with application latency.
By analyzing GC start events, developers can identify patterns such as frequent short pauses (indicative of minor GC spikes) or infrequent long pauses (potentially full GC regressions). These insights inform decisions about heap sizing, GC algorithm selection, and application memory usage patterns.
Optimizing GC Start Events
Optimizing the frequency and duration of GC start events involves several strategies:
- Heap Sizing – Increasing heap size can reduce the number of collections but may increase pause times.
- Garbage Collector Tuning – Parameters such as
-XX:MaxGCPauseMillis,-XX:G1NewSizePercent, and-XX:CMSInitiatingOccupancyFractioninfluence when and how GC starts. - Object Allocation Patterns – Reducing large object allocations and promoting object reuse can decrease GC pressure.
- Off-Heap Memory – Using off‑heap buffers (e.g.,
DirectByteBuffer) can reduce heap fragmentation and GC frequency.
Fine‑tuning these parameters requires iterative profiling: capture GC start events, measure application latency, adjust settings, and re‑profile. The goal is to achieve a balance between acceptable GC pause times and memory consumption.
Tools and Best Practices
Java Flight Recorder
JFR is the primary tool for capturing GC start events in modern JVMs. Key best practices include:
- Event Configuration – Enable only the necessary GC events to minimize overhead.
- Recording Duration – Use short recordings around suspected performance issues to capture relevant data without excessive disk usage.
- Analysis – Export recordings to CSV or use the JFR UI to filter by event type and time range.
GraalVM Native Image
GraalVM’s native image compilation eliminates the need for a traditional JVM, thus eliminating GC start events. However, developers should be aware of the trade‑off: native images provide faster startup times but require ahead‑of‑time compilation of all classes. When native images are used, monitoring focuses on application initialization and runtime performance rather than GC events.
Monitoring with Prometheus
Prometheus exporters can expose GC metrics, including pause durations and GC start counts. These metrics can be visualized in Grafana dashboards, providing continuous insight into GC behavior. Common exporters include:
jvm-gc-metrics– Exposes JMX metrics related to GC.jfr_exporter– Streams JFR events to Prometheus.
Setting alert thresholds on GC pause times helps detect regressions early.
Case Studies
Large-scale systems such as Netflix’s open‑source Hystrix library and Google’s Android operating system rely heavily on careful GC management. Netflix monitors GC start events via JFR and uses the data to tune the G1 collector for microservices with high throughput. In Android, the ART runtime's GC start logs inform the Android Open Source Project (AOSP) when new versions introduce performance regressions.
Another example is the use of jcmd GC.class_histogram during the development of a high‑performance analytics engine. By correlating GC start events with query latency spikes, engineers identified a memory leak in a data transformation library and fixed it, reducing average GC pause times from 120 ms to 18 ms.
Related Concepts
- Garbage Collection – Automatic memory reclamation process.
- Finalization – Legacy mechanism for resource cleanup.
- Memory Pools – Segmented heap areas (Eden, Survivor, Tenured).
- Concurrent Mark Sweep – GC algorithm minimizing pause times.
- Stop‑the‑World – Pausing application threads during GC.
- Heap Fragmentation – Uneven memory allocation leading to increased GC overhead.
- Off‑Heap Memory – Memory allocated outside the Java heap.
- JFR (Java Flight Recorder) – Low‑overhead event recording framework.
